General-purpose timer (TIMx)
RM0008
Bit 14 ECE : External clock enable
This bit enables External clock mode 2.
0: External clock mode 2 disabled.
1: External clock mode 2 enabled. The counter is clocked by any active edge on the ETRF
signal.
1: Setting the ECE bit has the same effect as selecting external clock mode 1 with TRGI
connected to ETRF (SMS=111 and TS=111).
2: It is possible to simultaneously use external clock mode 2 with the following slave modes:
reset mode, gated mode and trigger mode. Nevertheless, TRGI must not be connected to
ETRF in this case (TS bits must not be 111).
3: If external clock mode 1 and external clock mode 2 are enabled at the same time, the
external clock input is ETRF.
Bits 13:12 ETPS : External trigger prescaler
External trigger signal ETRP frequency must be at most 1/4 of CK_INT frequency. A
prescaler can be enabled to reduce ETRP frequency. It is useful when inputting fast external
clocks.
00: Prescaler OFF.
01: ETRP frequency divided by 2.
10: ETRP frequency divided by 4.
11: ETRP frequency divided by 8.
Bits 11:8 ETF[3:0] : External trigger filter
This bit-field then defines the frequency used to sample ETRP signal and the length of the
digital filter applied to ETRP. The digital filter is made of an event counter in which N events
are needed to validate a transition on the output:
0000: No filter, sampling is done at f DTS .
0001: f SAMPLING =f CK_INT , N=2.
0010: f SAMPLING =f CK_INT , N=4.
0011: f SAMPLING =f CK_INT , N=8.
0100: f SAMPLING =f DTS /2, N=6.
0101: f SAMPLING =f DTS /2, N=8.
0110: f SAMPLING =f DTS /4, N=6.
0111: f SAMPLING =f DTS /4, N=8.
1000: f SAMPLING =f DTS /8, N=6.
1001: f SAMPLING =f DTS /8, N=8.
1010: f SAMPLING =f DTS /16, N=5.
1011: f SAMPLING =f DTS /16, N=6.
1100: f SAMPLING =f DTS /16, N=8.
1101: f SAMPLING =f DTS /32, N=5.
1110: f SAMPLING =f DTS /32, N=6.
1111: f SAMPLING =f DTS /32, N=8.
Bit 7 MSM: Master/Slave mode
0: No action
1: The effect of an event on the trigger input (TRGI) is delayed to allow a perfect
synchronization between the current timer and its slaves (through TRGO). It is useful if we
want to synchronize several timers on a single external event.
358/995
Doc ID 13902 Rev 9
